| Product Configuration |
Product size: |
|
Total folded length (including extension pull rod): 93cm
Folded height: 70cm
Folded length: 48cm
Folded width: 25cm
Total adjusted height of folding pull rod: 93cm
Front wheels: 6-inch honeycomb wheels
Rear wheels: 12-inch honeycomb wheels
Wheelchair length: 83cm
Wheelchair width: 52cm
Wheelchair height: 85cm
Seat width: 40cm
Backrest height: 35cm
Seat-to-ground height: 51cm
Product net weight: 10kg
Maximum load capacity: 100kg
Product packaging dimensions: 52*27*76cm
|
unfolded size: 85*52*85cm |
Main Technical Parameters：
|
Name
|
Parameter
|
|
|
Total length
|
85cm
|
|
Total width
|
52cm
|
|
Total height
|
85cm
|
|
Fold length
|
50cm
|
|
Fold width
|
28cm
|
|
Fold height
|
73cm
|
|
Backrest height
|
36cm
|
|
Seat width
|
40cm
|
|
Seat depth
|
38.5cm
|
|
The height of the seat from the ground
|
51cm
|
|
Material quality
|
aluminum alloy /carbon steel
|
|
Front wheel
|
6inch
|
|
Front wheel
|
12inch
|
| Tire material |
PVC solid honeycomb wheel |
|
Maximum load
|
100kg
|
|
Net weight/Gross weight
|
10/11kg
|
|
Packaging size (L*W*H)
|
52*27*76cm
|
configure：
|
Front wheel
|
Standard 6-inch Shock-absorbing honeycomb wheels
|
 |
|
Back wheel
|
Standard 12-inch shock-absorbing honeycomb wheels
|
 |
|
Frame color
|
Standard: Black spray paint
|
 |
|
Pedal
|
Standard: configuration: Aluminum alloy
Optional:
high-strength carbon steel
|
 |
|
Braking function
|
Standard: New grip brake system with parking design
|
  |
|
Seat cushion material
|
Standard: Black Oxford fabric soft seat cushion
|
 |
Core Target Users:
Elderly individuals, patients, individuals with cerebral palsy, pregnant women, people with disabilities, those with limited mobility, etc.
Primary Usage Scenarios:
Hospitals, nursing homes, schools, high-speed trains, buses, airplanes, etc.
Product Features & Advantages
· Ergonomic Design: Contours to the lower back for a comfortable sitting posture.
· Telescopic Pull Handle Design
· Front and Rear Honeycomb Shock-Absorbing Tires
· Dual Spring Shock Absorption on Front Arms
· High-Strength Carbon Steel Main Frame with Strong Load-Bearing Capacity
· Foldable for Easy Storage and Portability, Can Be Carried On Board Airplanes
· Folding Lock Buckle, Can Be Opened with One Hand
· Simple to Use, Quick to Open and Fold
· No-Assembly Design, Pull-Up Buckles, Ready to Use When Opened, Folds for Compact Storage
· New Hand Grip Brake System, More Convenient to Use, Allows Braking and Locking, Prevents Rolling on Slopes
· Includes Safety Belt (Prevents Forward Leaning, Adjustable Length)
· Aluminum Alloy Footrest (Can Be Folded Up, High Load-Bearing Capacity)
· Assistive Step for Overcoming Obstacles
· Rear Storage Bag (For Storing Small Personal Items)
· [Optional: Dustproof Storage Bag]
